Ruijie-Reyee RG-ANT13-360 AirMetro 2Km 360° Omnidirectional Antenna

The Ruijie-Reyee RG-ANT13-360 is an external, omnidirectional antenna, featuring 5 GHz 2x2 MIMO technology and two spatial streams. Delivers a gain of up to 13 dBi with a horizontal angle of 360° and a vertical angle of 7°. It is specifically designed for the Ruijie-Reyee RG-AirMetro550G-B bridge for point-to-multipoint (PTMP) scenarios, covering a range of up to 2 km.

Highlights:

• Max. Throughput up to 867 Mbps at 5 GHz
• Up to 13 dBi Antenna Gain
• Angle H: 360°, V: 7°
• Up to 2 km Working Distance
• IP55 Rating against Harsh Environment
• [email protected]/h (30lbf@137mph) Wind Survivability
• All-in-one Cloud Management Simplifies the User Journey
• 3 Year Warranty

Specifications:

• Product Type: Omnidirectional  Antenna
• Mounting: Pole-mount
• Color: Elegant white
• Working Distance: 2 km
• Frequency Range:
  5.15 to 5.85 GHz
  Gain: 13 dBi
• HPOL Beamwidth: 360˚
• VPOL Beamwidth: 360˚
• Elevation Beamwidth: 7° (3 dB)
• Electrical Downtilt: 0°
• Max. VSWR: 2.0:1
• Wind Survivability: 220.32km/h (137mph) (GB 2423.41-1994)
• Wind Loading: [email protected]/h (30lbf@137mph)
• Polarization: Horizontal and vertical
• Cross-Pol Isolation: 25 dB Min.
• Certification: CE

Environment & Reliability​:

• Operating temperature: -40°C to +80°C (-40°F to +176°F)
• Storage temperature: -40°C to +85°C (-40°F to +185°F)
• Operating humidity: 5%-95% (non-condensing)
• Storage humidity: 5%-95% (non-condensing)
• Operating altitude: -500 m to + 5,000 m
• Storage altitude: -500 m to + 5,000 m
• MTBF: 400.000 hours (about 45 years)
• Cooling: Natural cooling
• IP rating: IP55

Dimensions & Weight:

• Unit Dimensions (LxWxH): 769 × 120 × 81.6 mm (excluding mounting bracket)
• Unit Weight: 1.06kg
• Package dimensions (LxWxH): 905 x 155 x 115 mm
• Package Weight: 2.35kg

​ PartnerNet-Ruijie-Reyee RG-ANT13-360 2Km Omnidirectional Antenna for AirMetro Series Wireless Bridges Datasheet

Package Contents:

• 1x RG-ANT13-360 Antenna (with Mounting Bracket)
• 2x RF Cable
• 1x User Manual
• 2x Pole Clamp
• 4x Hexagon Flange Nut
• 4x Cup Head Square Neck Bolt with Large Head















































































































































Χαρακτηριστικά
Κατασκευαστής	Ruijie
Τύπος Προϊόντος	Antenna
Max. Coverage Range	2km
Εγγύηση	3 Χρόνια
